Maintenance
4-15
HP6A Manual
Disassemble ratchet feed assembly by removing knob (37) and pressing out 1/8” spring pin (38). Ratchet
pawl (39), spring (40) and o-ring (41) can then be removed from carrier.
Remove Ratchet Actuator Assembly (42). Remove the four screws (43) holding the Ratchet Actuator
Assembly to the ratchet gear cage (44). Disassemble Ratchet Actuator Assembly. Loosen drag pin
housing Set Screw and unscrew the drag pin housing (45) (514-7-33), remove the spring (1) and the pin
(2) (refer to page 4.13).
