Page #180 background image
9 | Specifi cations EN-82
Manual | TM3-Primus
TP/PPM Bargraph
Description: PPM instrument displaying Peakmeter or TruePeak Meter
bargraphs with analog or digital scales and numerical dis-
play.
PPM instrument
Input sources: analog, digital, USB audio signals
Peakmeter: analog, digital: 2-ch. Stereo
USB: 2-ch. Stereo, 5.1 Surround
Display: Bargraph with fi xed colors:
- yellow: normal
- red: headroom
Numerical value on top of the bargraph
Analog Peakmeter
Analog scales: DIN5: +5 .. -50 dB
TP60: +3 .. –60 dB
Nordic: +12 .. -42 dB
BR IIa: 7 .. 1 (British)
SMPTE24: +24 .. –30
NHK
Zoom1: +1 .. -1 dB
Headroom: beginning (turning red) at:
0 dB on DIN5 scale
–9 dBTP on TP60 scale
+6 dB on Nordic scale
“6” on BR IIa scale
+6 dB on SMPTE24 scale
0 dB on NHK scale
Integration time: acc. to standard: Sample (TP60), 20 ms (BR IIa), 10 ms (all
others)
Specifi cations (continued)
