EN-89Manual | TM3-Primus 9 | Specifi cations
EN
VSC - Vectorscope
Description: 2-ch. Audio Vectorscope for displaying the phase relati-
onship between the channels of a channel pair (Lissajous
display).
Audio Vectorscope Instrument
Display mode: 2-channel
Inputs: L/R
AGC: fast
Grid: L/R
RTA
Description: Real Time Spectrum Analyzer instrument for displaying
the spectral content of the input channels using 31 fi lter
bands. Highpass fi lter for High Band (>20 kHz).
Real Time Spectrum Analyzer (RTA) Instrument
Functions: • Peak hold on/off
• Set reference
• Selectable resolution
Input sources: Stereo pairs
Frequency range: 20 Hz to 20 kHz, highpass fi lter for High Band (>20 kHz)
Number of bands: 1/3-octave: 31 bands, fi lter acc. to IEC 225 class 2
Weighting fi lter: Linear
Peak hold indicator: 4 s, 2 s, off
Measuring range: 45 dB max.
Resolution: 3, 6, 9 dB
Reference: 0.0 dB; adjustable from 0.0 to 21.0 dB in steps of 1 dB
Integration time (ballistics): Fast
Specifi cations (continued)
