9 | Specifi cations EN-90
Manual | TM3-Primus
Monitoring
Description: The Monitoring instrument provides a monitoring control
function which enables monitoring of displayed audio sig-
nals.
Monitoring Instrument
Functions: • Monitor level control with onscreen level fader
• Mute, Dim
• Internal Downmix for multichannel monitoring, audio
output of monitoring signals via S/PDIF out connector.
Output: Digital 2-ch. Stereo (S/PDIF out, unbal., RCA-F)
Correlator
Description: Stereo Correlator instrument for displaying the phase rela-
tionship between the two channels of a stereo signal and
thus its mono compatibility.
Correlator Instrument
Display: Bargraph, additional spot indicator between PPM bar-
graphs
Scale range: –1 r to 0 to +1 r
Standard color setting: red: –1 r to –0.1 r
white: 0 r (–0.1 r to +0.1 r)
green: +0.1 r to +1 r
Attack/release time: 1.0 s/2.5 s
Specifi cations (continued)
