30
Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
Figure 16. ZF7025-US rear panel
Table 21. ZF7025-US rear panel features
Number Name Description
1 PoE In LAN 5/Uplink Uplink LAN port that supports 802.3af and 802.3at
Power over Ethernet (PoE) input.
2 Punch down Block 110 punchdown block.
3 Pass Through Port RJ-45 pass through port for the pass through
connection.
4 LEDs See Tab le 24
for LED descriptions and behaviors.
