47
Installing the Access Point
Step 1: Preconfigure the Access Point
Figure 28. The Configuration > Wireless > Common tab
Configure Wireless # Settings
1. Click one of the Wireless # tabs.
2. In Wireless Availability, click Enabled.
3. In Broadcast SSID, click Enabled.
4. Clear the SSID box, and then type a unique and descriptive name that you want
to call this wireless network.
For example, you can type Ruckus Wireless AP. This SSID is the name that
will help users identify this wireless network in their wireless network connection
application.
NOTE: You may also configure other wireless settings on this and other Wireless #
tabs (in addition to the settings described above), although it is not necessary for
completing the Access Point installation.
5. Click Update Settings.
You have completed configuring the basic wireless settings of the Access Point.
