Hardware Installation and Reference Guide Product Overview
8
DC input:
Rated voltage: -36V to -72V
Rated current per input: 3.15A
The RG-PD70I power module is only suitable for use in the Chinese region.
SFP Port
Not supported
SFP+ Port
10GBase-R
1000Base-X
Power
Consumption
<45W (without expansion modules)
Temperature
Operating temperature: 0 ºC to 50ºC
Storage temperature: -40 ºC to 70ºC
Humidity
Operating humidity: 10% to 90% RH
Storage humidity: 5% to 95% RH
Altitude
0 to 5000m
Fan
Speed adjustment and fault alarm
Temperature
Alarm
Supported
EMI Standard
GB/T 9254.1
Safety
Standard
GB 4943.1
Dimensions
(W x D x H)
440 mm x 300 mm x 44 mm
Weight
4.2 kg
Product Appearance
The RG-S5750C-48GT4XS-H Ethernet switch provides 48 10/100/1000Base-T Ethernet ports, 4 10GE
SFP+ ports, 1 MGMT port, 1 USB port, 1 Mini USB port, and 1 Console port on the front panel, as well
as 2 power module slots and 2 expansion module slots on the back panel (The Console and Mini USB
ports are a combo Console port. When they are connected meanwhile, the Mini USB port takes the
precedence).
Figure 1-5 Appearance of RG-S5750C-48GT4XS-H
