Ruijie RG-S5750-H Series User Manual

Hardware Installation and Reference Guide Product Overview
11
LED
Panel
Identification
State
Meaning
1. Temperature of inlet/outlet air
exceeds the normal operating
temperature range.
2. The power supplies cannot support
the whole system.
Check the working environment of the
switch and power supplies immediately.
Solid red
The switch is faulty. For details, see the
chapter “Troubleshooting”.
Power status LED
PWR1/PWR2
Off
The power module is not in place or not
receiving power.
Solid green
The power module is connected and
can supply power.
Solid red
The redundant power is faulty or the
AC power cord is not connected.
MGMT port status
LED
MGMT
Off
The port is not connected.
Solid green
The port is connected at 1000 Mbps.
Blinking green
The port is receiving or transmitting
traffic at 1000 Mbps.
Solid yellow
The port is connected at 10/100 Mbps.
Blinking yellow
The port is receiving or transmitting
traffic at 10/100 Mbps.
10GE SFP+ port
status LED
49F-52F
Off
The port is not connected.
Solid green
The port is connected at 1/10 Gbps.
Blinking green
The port is receiving or transmitting
traffic at 1/10 Gbps.
10/100/1000Base-
T Ethernet port
status LED
1-48
Off
The port is not connected.
Solid green
The port is connected at 1000 Mbps.
Blinking green
The port is receiving or transmitting
traffic at 1000 Mbps.
Solid yellow
The port is connected at 10/100 Mbps.
Blinking yellow
The port is receiving or transmitting
traffic at 10/100 Mbps.
1.3 RG-S5750C-28SFP4XS-H
Technical Specifications
Model
RG-S5750C-28SFP4XS-H
CPU
Dual-core with each 1.0 GHz

Ruijie RG-S5750-H Series Specifications

General

Brand	Ruijie
Model	RG-S5750-H Series
Category	Switch
Language	English
