Hardware Installation and Reference Guide Product Overview
10
The RG-S5750C-48GT4XS-H supports two power modules. For details, see the section “Power
Modules”.
Dual-power input: The switch can be powered by one power module, or two power modules. When both
two modules are available, the switch is powered in current sharing mode.
When the switch is powered by the dual-power modules, if the system working power is greater
than the capacity of single power module, power redundancy cannot work; if one power module
fails, the switch system will be affected.
Heat Dissipation
RG-S5750C-48GT4XS-H adopts left and right fans for heat dissipation, thereby ensuring the normal
function of the device in the specified environment. Sufficient space (10 cm distance from both sides
and the back panel of the cabinet) should be reserved around the cabinet to allow air circulation.
Figure 1-8 Flow Scheme of Heat Dissipation
LED
The switch is not receiving power.
The switch is being initialized with 3Hz
blinking.
Continuous blinking indicates errors.
Supports remote on/off to locate the
switch.
The switch is operational.
