RACK INSTALLATION
+ +
ACA-E5 Controller side view
Rack ear
front view
Rack ear
side view
Rack ear
screw holes
+ +
ACA-E5 Controller front view with rack ears installed
EXERCISE ROOM
RACK MOUNT INSTALLATION
To attach the rack ears, locate the eight rack
mount holes on each side of the controller’s chassis.
Align the holes in the rack ears with the holes in the
chassis. Insert and tighten the screws.
