Russound ACA-E5 Installation Manual
39
ZONE AUDIO/VIDEO OUTPUTS
CAT-5 cable
(up to 250 ft.)
RCA
cable
Speakers
Video display
RCA cable
CAT-5 cable
Speaker cable
RNET A/V Decoder
RJ45 wall plate
RJ45 wall plate
Front Back
ACA-E5 controller with video display connected through RNET A/V output
