14
2) Select capillary glass.
Model
Specification(O.D.×I.D.×length)
B-15086-10F
1.5×0.86×100 mm
B-10050-10F
1.0×0.5×100 mm
B-10078-10F
1.0×0.78×100 mm
B-12069-10F
1.2×0.69×100 mm
B-12094-10F
1.2×0.94×100 mm
B-150110-10F
1.5×1.1×100 mm
Figure 4-9
3) Select the application of microelectrodes.
Figure 4-10
4) Finally, the system generates program parameters based on the above three options, and
the current protocol can be used as a new program or overwrite current parameters.
