RWD MP-500 - Start and Pause; Program List

15
Figure 4-11
4.6 Start and pause
The green button [START/STOP] is a multi-function button, which can start or pause pulling; the
red button [RESET] can restart the system.
4.7 Program List
Click in the [Main Interface] as shown in Figure 4-2 to save the softening point
value and all current parameters.
Click on the [Main Interface] to view all saved programs. Up to 99 items can be
saved.
Figure 4-12
Double Click the selected program to open the program;
