RWD MP-500 - Edit Parameters; Pull Protocol

13
4.4 Edit Parameters
In the interface shown in Figure 4-7, each parameter can be edited.
Figure 4-7
4.5 Pull Protocol
In the [Main Interface], click to select the preset protocols of RWD for pulling.
1) Select the heating filament model. Heating filaments are all box-shaped. When the
microelectrode used in vivo microinjection, RWD recommends the HF-2545B filament.
Model
Specification(box length×width)
HF-3025B
3.0×2.5 mm
HF-3030B
3.0×3.0 mm
HF-2545B
2.5×4.5 mm
Figure 4-8
