32
Figure 6-4
5) Replace the jaw ② corresponding to the size of the new filament, and tighten the screw ①.
Note that the jaw groove ② should be flush with the jaw ③, as shown in Figure 6-4.
6) Clamp capillary glass in the right puller bar, and make left end of the glass in the middle
between two brass jaws, as shown in Figure 6-5.
Figure 6-5
7) Install the new heating filament on the jaw to make the glass go through the center of the
filament, and put in two screws①②. Be careful not to tighten the screws at this time, as shown
in Figure 6-6.
Figure 6-6
To prevent potential damage, do not pinch the filament or touch it with sharp objects
such as tweezers tip.
①
②
③
