Enable teach-in/ confi-
guration mode
Short button press LED flashes
orange
Disable teach-in/ confi-
guration mode
Short button press LED lights up red:
Teach-in process
unsuccessful
LED lights up
green:
Teach-in process
successful
Call up menu Long button press LED flashes red
Wireless network test Short button press
Reset to
delivery status
Long button press
The acoustic signal generator (buzzer) of the wireless module
acknowledges every short and long press of the wireless module
tbutton. A „long press“ is one that lasts around 5 seconds. The
operating LED visually signalises the current staus.
ConfigurationTest
