LOOSE PARTS LIST
1. Seat assembly with safety interlock cable
x 1
2. Steering column assembly
Upper steering shaft x 1
Bolts x 2
Steering column x 1
Steering column cover x 1
Flange washers x 2
Spring x 1
Steering wheel hub x 1
Steering wheel x 1
Flat washer x 1
Flange nut x 1
Steering wheel cover x 1
5.
2.
4.
3. Charger x 1
4. Bumper x 1
5. Keys x 3
6. Operator's manual (not shown)
WARNING
If any parts are damaged or missing do not
assemble the product until the parts are
replaced with new original manufacturer’s
parts. Assembling the product with
damaged, missing, or incorrect parts could
result in serious personal injury.
14
