BRAKE PEDAL
The brake pedal slows down or stops the
product.
CHARGER
The charger recharges the batteries of the
mower. It has a key hole hanging feature
for convenient, space-saving storage. When
hanging by the keyhole slots, use at least one
additional screw in the hole in the mounting
ange to secure in place. Always mount in
such a way that the charger’s LED status light
is visible while charging.
CRUISE CONTROL BUTTON
The cruise control button allows the product
to continue forward at a set speed without
needing to step on the accelerator pedal.
DECK HEIGHT ADJUSTMENT LEVER
The deck height adjustment lever raises or
lowers the cutting deck.
DIRECTION CONTROL SWITCH
The direction control switch controls the
direction movement of the mower. Available
settings are forward (F), neutral (N), and
reverse (R).
HEADLIGHT BUTTON
The headlight button turns the headlights on
and o󰀨.
MEDIA HOLDER
The media holders provide a convenient place
to store your mobile phone or MP3 player
when charging with the USB port.
MULCH COVER
The mulch cover covers the side discharge
opening, which allows the mower blade to cut
and recut for ner clippings.
PARKING BRAKE
The parking brake locks the product in the
brake position.
POWER SWITCH WITH START KEY
The power switch turns the product on and
o󰀨. The start key must be inserted before the
switch can be operated.
REVERSE MODE BUTTON
The reverse mode button allows the product
to cut when maneuvering in the reverse
direction. The blades stop if the product is
operated in reverse without pressing the
reverse mode button.
NOTE: The blade engage knob must also
be pulled up for mowing to occur when
maneuvering in reverse.
SEAT ADJUSTMENT LEVER
The seat adjustment lever moves the seat to
the preferred position.
USB PORT
The USB charging port provides charging
power of 5 Volts DC at up to 2 amps for your
mobile phone, MP3 player, or other USB
devices. Check the manual of your device for
specic charging requirements.
Connect one end of a USB cable (not
provided) to your device and the other end to
the USB charging port on the product to begin
charging your device.
NOTE: The USB port is only powered when
the start key is in the on position.
WARNING
Never use headphones or any electronic
device, such as a smart phone or tablet,
while operating the product. A lapse in
concentration while operating the product
may result in serious personal injury to the
operator or a bystander.
APPROVED HITCH POINT
The approved hitch point can be used for
towing loads not more than 226.8 kg. (500
lbs.).
