Ryobi RM480e - Charging the Product; Final Checks

INSTALLING THE BUMPER
See fig. 5
1. Remove the flange nuts and hex head
bolts that secure the bumper cover to the
mower frame.
2. Install the bumper into the openings at the
front of the mower frame as shown.
3. Align the holes in the bumper, the
mower frame, and the bumper cover.
Reinstall and securely tighten the
hex head bolts and flange nuts.
HEX HEAD BOLTS
BUMPER
FLANGE
NUT
FLANGE
NUT
BUMPER COVER
FINAL CHECKS
CHECKING THE TYRE AIR PRESSURE
Check the air pressure in all tyres before
use. Improper air pressure a󰀨ect[s handling,
steering response, traction, tyre life, level
cutting, and operator comfort. Make sure
that tyres are inated to the recommended
pressure of 1.6 bar (158.58 kPa).
NOTE: Measure and adjust the air pressure
only when the tyres are cold.
WARNING
Check the tyre pressure carefully while
inating. Too much air in the tyre could
cause the tyre to burst, causing serious
personal injury.
CHARGING THE PRODUCT
See fig. 6
Mower batteries must be charged for 24 h
before rst use. To verify that the mower
batteries are fully charged, check the battery
level indicator.
To charge:
1. Connect the charger plug into the
charging port on the mower, making sure
that it is properly connected.
2. Connect the charger to a power supply
that uses normal household current of
of 100-240 VAC, 50/60 Hz. The batteries
should automatically begin to charge.
NOTE: Do not charge the product in an area
of extreme heat or cold.
3. Disconnect the charger from the mower
once it is fully charged and ready for use.
CHARGER PLUG
CHARGING
PORT
Fig 6
WARNING
To avoid accidental starting or movement
of the product that could result in serious
personal injury, always remove the start key
and engage the parking brake when leaving
the product unattended.
WARNING
Always connect the mower to the charger
when it is not in use. If it is not possible to
leave the mower charger connected, make
sure to fully charge the batteries at least
once a month.
Fig 5
17
