Ryobi RM480e - Tyre Maintenance

BLADEWRENCH BLOCK OF WOOD
Fig 24
BLADE HALF
CIRCLE POST
SHAFT
BLADE
CIRCLE
POST
BLADE
INSULATOR
BLADE
BLADE
NUT
SPACER
BLADE HALF
CIRCLE HOLE
BLADE
CIRCLE
HOLE
CENTER
BLADE
HOLE
Fig 25
STRAIGHT
SIDES
ALIGNED
Fig 26
TYRE MAINTENANCE
The product is equipped with tubeless tires
with the following dimensions:
■ Front tyres: 38.1 x 15.2 x 15.2 cm
(15 x 6 x 6 in.)
■ Rear tyres: 40.6 x 16.5 x 20.3 cm
(16 x 6.5 x 8 in.)
Tyre air pressure
Check the air pressure in all tyres before use.
Improper air pressure a󰀨ects handling, steering
response, traction, tire life, level cutting, and
operator comfort. Be sure tires are inated to
the pressure of 1.6 bar (158.58 kPa).
NOTE: The air pressure should only be
measured or adjusted when the tyres are cold.
WARNING
Check the tyre pressure carefully while
inating. Too much air could cause the tyre
to burst, causing serious personal injury.
32
