TAB
SEAT
TAB
SAFETY
INTERLOCK
CABLE
WIRING
COVER
HEX HD.
BOLT
BATTERY
QUICK-CONNECT
PLUG
Fig 31
SCREWS
BATTERY
COMPARTMENT COVER
Fig 32
FLANGE
BOLTS
BATTERY
TRAY
FLANGE
Fig 33
WARNING
The battery tray is very heavy and requires
two people to extend. Use a hydraulic
tabletype cart (or similar device) to extend
the tray. Failure to properly extend and
support the battery tray could result in
serious personal injury, and damage to the
mower.
WASHER
LOCK WASHER
BLACK ( – )
RED ( + )
SECURING
BRACKET
BATTERY
COVERS
Fig 34
