Saab R60 - Status Monitoring

R60 Station
R60 User Manual
Document Number
Version
Date
7000 120-019
A1
2022-08-10
Page 15 (98)
Item
Description
The R60 is configured for hot standby and is currently operating in
standby mode.
Soft LED. Blinks yellow when receiving.
Soft LED. Blinks red when transmitting.
2.2.3 Status
R60 status is displayed in a number of groups according to the table below.
Group
Parameter
Description
R60 Station
Temperature
Current temperature inside the unit.
AC
AC power available
DC
DC power available
DC Voltage
DC power voltage level
Source
Current power source (AC or DC)
State
Indicates R60 stations state:
Booting: R60 station is starting up
Operational: R60 station is operational
Loading software: Software load in progress, R60 station is not
operational
Failure: System failure, R60 station is not operational.
Uptime
R60 station supervisor uptime in days hh:mm:ss
GNSS
Source
Current GNSS source
Visible
Satellites
The number of GNSS satellites that theoretically could be detected at the
R60 location.
Satellites in
Use
The number of GNSS satellites that are received and used by the R60.
Self-
Surveyed
Position
Latitude
Latitude
Longitude
Longitude
Altitude
Altitude in meters
Accuracy
Self-surveyed position accuracy in percent
Hot Standby
Hot Standby
Mode
Current hot standby mode, available modes are:
Not active
Manual
Autonomous
Hot Standby
Status
Current hot standby status:
Master
