11 TECHNICAL DATA
PHYSICAL DATA
Type
19” rack mount. Unit height: 2U
Dimensions
Height:
Width:
Depth:
89 millimetres (3.51”)
483 millimetres (19.02”)
357 millimetres (14.06”)
Weight:
4.5 kilograms (10 Lbs)
DC-POWER
Power input requirements
10.8-31.2 V
Grounding
The negative DC feed is isolated from the chassis.
Current need (typical):
During transmission
- with 12.5W VHF output power setting
- with 1W VHF output power setting
Operating (except during transmission)
Off, but supplied with DC only
Normal operation
@ +24 V
109 W/4.52 A
61 W/2.55 A
19 W/0.78 A
1.6 W/65 mA
22 W/0.9 A (5 BTU)
Recommended fuse
20 A (T20A 50VDC ) 5x20mm
AC-POWER
Power input requirements
100-240 volts @ 50/60 Hz
Power consumption (typical):
During transmission:
- with 12.5W VHF output power setting
- with 2W VHF output power setting
Operating (except during transmission)
Off, but supplied with AC.
Normal operation
110 W
74 W
51 W
21 W
53 W (11 BTU)
Recommended fuse
3 A ( T3A 250V ) 5x20mm
VHF TRANSCEIVER
Frequency
155 – 162.5 MHz
Channel Bandwidth
25 kHz, future VDE options 50 kHz, 100 kHz
Channel Selection
Channel numbers as in ITU-R M. 1084-4
Output power
AIS: LOW (1W) and HIGH (12.5W)
ASM: from 1W to 12.5W
Bit rate (Tx/Rx)
9.6 kbps (AIS), 19.2 kbps (ASM), 307.2 kbps
(VDE option max bit rate)
Modulation
GMSK (AIS)
FSK (DSC)
π/4 QPSK (ASM and VDE option).
16-QAM (VDE option)
ELECTRICAL INTERFACES
Data Ports
RS-232/422 V11. Bit-rate up to 115 200 bps
TCP/IP Port
3 x Ethernet (UDP, UDP Multicast, TCP)
Up to 10 simultaneous TCP data clients
GNSS-Antenna
TNC-Female, with 5V @ 40mA power supply to
GNSS antenna pre-amplifier
1PPS and IRIG-B 003
Via 9-pin D-sub (male)
VHF-Antenna
N-Female, separate RX and TX antenna ports
(option)
Digital Input and Output Port
Via 9-pin D-sub (male)
