Group
Parameter
Description
DAC
Designated Area Code for the binary AtoN Status Message.
FI
Functional Identifier for the binary AtoN Status Message.
Digital Input
Change Tx
Max
Tokens
The maximal number of TX tokens that can be available for extra
transmits, due to digital input changes.
0 = Disables transmits due to digital input changes.
1 – 10 = Max number of TX tokens.
Token Rate
Interval in seconds (3 – 180) between TX tokens being added.
DIO 0-23
Selects which digital inputs to monitor for digital input changes.
Deselecting all will disable transmits due to changes in digital inputs.
Met/Hydro
Message
Active
Check this box in order to enable transmission of the metrological
and hydrographical message (DAC 1, FI 31).
Report
Rate
The interval in seconds (10 – 86400) between transmitted
met/hydro messages.
Visibility
Sensor
Max Range
Maximal range of visibility sensor.
Range
Formula for calculating the range (in NM) based on current (in mA)
from external interface unit.
Table 6-18 – Parameters for the Special AtoN Functions
