Saab TankRadar
®
ProIntroduction
1-2
Edition 2. Ref. No: 306010E
If HART technology is used you can configure and monitor measurement
data via a hand held communicator or a PC.
For stand-alone systems, or as a complement to a PC or a control system,
you can monitor level data using one or two analog outputs depending on
the particular hardware configuration.
As an option, your TankRadar Pro gauge can be equipped with an easy-to-
use display panel. It offers basically the same functionality as the Pro Setup
software package. Four sturdy softkeys gives you access to configuration
routines, service functions and level monitoring.
123
456
789
Display Panel
RTG 40
Analog
Instrument
Analog
Instrument
Hand Held HART
Communicator
Control System
HART
Interface
