Saab TankRadar PRO - Internal Connections

3-12
Edition 2. Ref. No: 306010E
Saab TankRadar
®
ProElectrical Installation
X2
5
4
3
1
2
6
X5 X6
DPS
DP+
SO-
SO+
PO+
PO-
IS Gnd
X7
DI40
X7
P
5
4
3
1
2
X1
L+
L-
PO+
PO-
X3
X4
X4
D
DC40
X4
A
AC40
X2
6
5
4
3
2
1
X5 X6
X7
X1
1
2
3
4
5
X3X4
Non-Intrinsically Safe (EEx e) Intrinsically Safe (EEx i)
Internal Connections
Option Description Board
0 No Display Panel NA
P Display Panel DI40
Option Description Board
A 100 - 240 VAC AC40
D 24 - 48 VDC DC40
Power Supply
Display Panel
