Saab TankRadar PRO - Electrical Installation; Identification of Installed Options

Saab TankRadar
®
Pro Electrical Installation
3-1
Edition 2. Ref. No: 306010E
FCC ID K8CPRO
EEx de[ib]ib IIC T4(T
amb
-40°C, +70°C)
I. S. Options:
DI 40 HM 40+IS 40 XA 40+IS 40
Non-I.S. Options/Power Supply:
AC 40 (85-260 VAC, 10W)
Serial No:
1434
SCS Ex97D1028
N
E
P
A
S
O
U
V
R
I
R
S
O
U
S
T
E
N
S
IO
N
.
H
A
Z
A
R
D
O
U
S
A
T
M
O
S
P
H
E
R
E
S
D
O
N
O
T
O
P
E
N
W
H
E
N
E
N
E
R
G
I
Z
E
D
.
T
O
P
R
E
V
E
N
T
I
G
N
I
T
I
O
N
O
F
I II III
IV
V
Approval
Power Supply
Primary Output
Display Panel
Secondary Output
3 Electrical Installation
Identication of
Installed Options
I Approval
C Cenelec
FFM
P PTB
X Other certificates
II Power Supply
A 100 - 240 VAC nominal power
D 24 -48 VDC nominal power
III Primary Output
1A Non-IS HART/4-20 mA,
active.
1C Non-IS HART/4-20 mA,
passive.
1B IS HART/4-20 mA,
active.
1D IS HART/4-20 mA,
passive.
2A TRL2 Bus
IV Display Panel
0 No display panel
P Display panel
V Secondary Output
0 No secondary output
A Non-intrinsically safe 4-20 mA,
active.
B Intrinsically safe 4-20 mA,
active.
C Non-intrinsically safe 4-20 mA,
passive.
D Intrinsically safe 4-20 mA,
passive.
Note! If you change
optional circuit boards
the label must be
exchanged to show the
current inputs and
outputs.
