Saab TankRadar PRO - Pro Setup Software

Saab TankRadar
®
Pro Pro Setup
4-1
Edition 2. Ref. No: 306010E
4 Pro Setup Software
The Pro Setup software is an easy to use PC program for con-
figuration of the Saab TankRadar Pro transmitter. It is designed
to run under Windows95/NT4.0. It also includes options for
viewing tank data as well as options for advanced service.
It is a simple task to start and configure the TankRadar Pro trans-
mitter. When the gauge is mounted on the tank flange, and the
cables are properly connected you only need to run through a
straightforward configuration procedure to start the transmitter.
In this procedure you will set a few parameters to optimize the
performance of the gauge for your particular application:
 Tank dimensions
 Type of application.
 Analog out: source, range and alarm mode.
 Volume calculations (optional).
 Tank environment (for the disturbance echo handling).
PC
Modem
RTG 40
