User Manual Laser Diode Controller PilotPC 21
Laser, TEC and System status field gives the user an direct overview in
every mode.
Laser Status Field
Laser Status field shows the user the most important laser parameters.
These are
- Laser Current (in I-Mode)
- Photodiode Current (in P-Mode)
- Laser Polarity
(POS = Cathode grounded LD /NEG = Anode grounded LD)
- Current Limiter active
TEC Status Field
TEC Status field shows the user the most important TEC parameters.
These are
- TEC Current
- TEC Temperature
- TEC Sensor
