User Manual Laser Diode Controller PilotPC 22
System Status
PZ FG CC EM
RM STA 12345
The system status field contains important labels which gives the user
information about specific options and an error code which is generated
by the driver diagnostic module.
Label
Description Comment
TC Temperature Coupling
PZ Piezo Driver enabled
FG Function Generator enabled
CC Current coupling enabled
EM External Modulation enabled
RM Driver is in Remote Operation Mode is blinking when a non
valid command is sent
STA Error
occurs
Error code is explained
in the appendix chapter
Stored set values
All set values will be stored in a non volatile memory so that they are
still present after you turn the driver OFF
Note!
The set values are only stored when the driver is
switched OFF by the line switch at the front panel
