Saftronics FP5/GP5 Series - 12.1 Constant List

Chapter 12: Constant List
Firmware – S2011 and S3012
Revision: 1 (9/98) 84 © Saftronics, Inc.
12.1 Constant List
Table 27 Constant List
Constant Function Name Description
Factory
Setting
n001 Password
0 : n001 read and set, n002 to n108 read only
1 : n001 to n034 read and set, n035 to n108 read only
2 : n001 to n049 read and set, n050 to n108 read only
3 : n001 to n108 read and set
4 : Not used
5 : Not used
6 : 2-wire initialization − reset (Japanese standard)
7 : 3-wire initialization − reset (Japanese standard)
8 : 2-wire initialization − reset (U.S. specifications)
9 : 3-wire initialization − reset (U.S. specifications)
10 : 2-wire initialization – reset (European specifications)
11 : 3-wire initialization – reset (European specifications)
1
n002 Operation mode selection
(Setting) (Operation) (Reference)
0 : Operator Operator
1 : Terminal Operator
2 : Operator Terminal
3 : Terminal Terminal
4 : Operator Serial com
5 : Terminal Serial com
6 : Serial com Serial com
7 : Serial com Operator
8 : Serial com Terminal
3
n003 Input voltage
Unit : 0.1V
Setting range : 150.0 to 255.0V (510V for 400V units)
200.0V
(400.0V)
n004 Stopping method selection
0 : Deceleration to stop
1 : Coast to stop
2 : Coast to stop with timer 1
3 : Coast to stop with timer 2
0
n005 Power rotation
0 : CCW
1 : CW
0
n006 Reverse run prohibit
0 : Reverse run enabled
1 : Reverse run disabled
0
n007 LOCAL/REMOTE key function
0 : Disabled
1 : Enabled
1
n008 Stop key function
0 : STOP key is effective when operated from Digital Operator
1 : STOP key is always effective
1
n009
Frequency reference setting method
from Digital Operator
0 : ENTER key not used
1 : ENTER key used
1
n010
V/f pattern selection (same as V/f
LED)
0 to E : 15 preset V/f patterns
F : Custom V/f pattern with voltage limit
FF : Custom V/f pattern without voltage limit
1
n011
Motor rated voltage
(same as Vmtr LED)
Unit : 0.1V
Setting range : 150.0 to 255.0V (510 V for 400V units)
200.0V
n012 Maximum output frequency
Unit : 0.1Hz
Setting range : 50.0 to 400.0Hz
60.0 Hz
n013 Maximum voltage
Unit : 0.1V
Setting range : 0.1 to 255.0V (510 V for 400V units)
200.0V
n014 Maximum voltage output frequency
Unit : 0.1HZ
Setting range : 0.2 to 400.0V
60.0Hz
n015 Middle output frequency
Unit : 0.1Hz
Setting range : 0.1 to 399.9Hz
3.0Hz
n016 Middle frequency voltage
Unit : 0.1V
Setting range : 0.1 to 255.0V (510V for 400V units)
15.0V
n017 Minimum output frequency
Unit : 0.1Hz
Setting range : 0.1 to 10.0Hz
1.5Hz
n018 Minimum output frequency voltage
Unit : 0.1V
Setting range 0.1 to 50.0V
10.0V
n019
Acceleration time 1
(same as Accel LED)
Unit : 0.1 seconds (1 seconds for 1000 seconds and above)
Setting range : 0.0 to 3600 seconds
10.0
seconds
n020
Deceleration time 1
(same as Decel LED)
Unit : 0.1 sec (1 seconds for 1000 seconds and above)
Setting range : 0.0 to 3600 seconds
10.0
seconds
n021 Acceleration time 2
Unit : 0.1 seconds (1 seconds for 1000 seconds and above)
Setting range : 0.0 to 3600 seconds
10.0
seconds
