6-
dvanced parameters
F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Page 6-57
6.4.6
S
ecurity
6.4.6.1 IP Filtering
Outgoing
Object: This menu is used to create outgoing IP filters to refuse data from the LAN to the WAN and list the
existing outgoing IP filters.
By default, all the outgoing data is accepted.
• In the Advanced Setup menu, select Security > IP Filtering > Outgoing.
The following screen opens:
Field
Meaning
Filter Name Name of the filter.
IP Version IP version used.
Protocol Transport protocol.
SrcIP/ PrefixLength
"Source" address (your computer, for example) and
associated subnet mask.
Source Port Source port.
DstIP/ PrefixLength
"Destination" address (a machine on the Internet, for
example) and associated subnet mask.
DstPort Destination port.
Remove
Check the box and click on the [Remove] button to
remove the object from this list.
To Next Page
