F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document. Reproduction and disclosure prohibited
Page 6-17
6-
dvanced parameters
6.4.1
Layer2
Int
e
rface
Object: This menu is used to configure DSL interfaces.
This section contains the following menus:
• ATM Interface (see subsection 6.4.1.1)
• ETH Interface (see subsection 6.4.1.3)
6.4.1.1 ATM Interface
Object: This menu is used to configure DSL ATM interfaces.
• In the Advanced Setup menu, select Layer2 Interface then ATM Interface.
The following screen opens:
Field
Meaning
Interface Name of the DSL ATM interface, allocated automatically.
Vpi Value of the VPI.
Vci Value of the VCI.
DSL Latency DSL Latency.
Category Type of service adapter to the traffic.
Peak Cell Rate
(cells/s)
Maximum allowable rate at which cells can be transported along the
connection in the ATM network.
