Configuration with the Service Interface
98-139768-A Chapter 4: Configuration 4-11
4444
Configuration
Use scenario 1: Printer and ThraneLINK compatible print server
To set up a printer that is compatible with a ThraneLINK print server, e.g. the SAILOR 6004
Control Panel, do as follows:
1. Connect the printer to one of the two USB ports of the SAILOR 6004 Control Panel.
2. Switch on the SAILOR 6004 Control Panel and the printer attached.
3. Click Find printers in the section Automatic printer lookup. Then a list with serial
numbers of the available ThraneLINK print servers with attached printers is displayed.
4. Click the serial number of the desired print server, e.g. a serial number of a SAILOR 6004
Control Panel.
5. Click Save to save the printer settings in the SAILOR 6390 Navtex Receiver.
Use scenario 2: 3rd party printer
To set up a 3rd party printer do as follows:
1. At Setting, IP select Static.
2. Fill in the Static IP (IP address), Port number and LPR Queue Name. See the
documentation of the printer server
3. Click Save save the printer settings in the SAILOR 6390 Navtex Receiver.
Use scenario 3: Disable printer
Click Disable Printer if you do not intend to install a printer for printing Navtex messages.
Then the SAILOR 6390 Navtex Receiver will not give printer alarms.
