A.1 SAILOR 6390 Navtex Receiver
Item Specification
Weight 1.3 kg
Dimensions L x W x H: 190 x 270 x 42.5 mm
Input voltage 12-24 VDC (10.8 VDC to 31.2 VDC)
Power
consumption
Typical 6.5 W
Heat dissipation <10 W
Temperature -15 °C to +55 °C (Operational)
-15 °C to +55 °C (Storage)
Compass Safe
Distance
20 cm (Standard magnetic compass)
20 cm (Emergency magnetic compass)
IP rating IP22 (estimated)
Navtex receivers 490 kHz, 518 kHz and 4209.5 kHz simultaneous
reception.
Software updatable for 500 kHz NAVDAT
Antenna support Active and passive antenna (12 V @ 60 mA antenna
supply)
Sensitivity
490/518 kHz
4209.5 kHz:
<12 dBV@10 /150 pF
<-6 dBV@50
<12 dBV@10 /150 pF
<6 dBV@50
Interfaces TNC antenna connector
Alarm relay output (normally closed)
2 LAN connectors
Remote on
NMEA0183 in and out for INS support
NMEA0183 in for e.g. GPS input
600 single ended audio interface for troubleshooting
Printer Support via LAN connector
NMEA sentences NMEA0183 input, EN61162-1: ACK, NRM, CRQ
sentences
NMEA0183 output, EN61162-1: ALR, NRM, NRX
sentences
GPS input: RMC, ZDA sentences
Proprietary sentences
Table A-1: SAILOR 6390 Navtex Receiver specifications
