Heating plus Hot Water Arrangement
This is the arrangement for installing an iT500 based control system with a single heating zone and hot water.
The iT500RX Receiver is hardwired to the heating and water system components.
The iT500 Thermostat is connected wirelessly to the iT500RX Receiver.
Hot
Water
Tank
Boiler
iT500
iT500RX
ALL RADIATORS
iT5
00
A
L
L
R
L
iT500RX
