10 PCB Layout and Parts List
10-4 SAM4S ER-380M/F SERIES
10-1 Main PCB Layout
10-1-1-(b) Parts List
No Part-No Description / Specification Q’TY Design Location
Serviceabl
e
Remark
s
- 0903-001155 IC-MICROCOMPUTER:30800SFP,16BIT,QFP,100P 1 U10
- 0904-000411 IC-PERIPHERAL:82C55,8BIT,PLCC,44P 1 U18
- 0909-000137 IC-REAL TIME CLOCK:RS5C372A,SSOP,8P 1 U14
- 1003-001234 IC-MOTOR DRIVER:LB1838M,SOP,14P,173MIL,S 1 U6
- 1006-000133 IC-DRIVER/RECEIVER:232,SOP,16P,150MIL,DU 1 U1
- 1006-000133 IC-DRIVER/RECEIVER:232,SOP,16P,150MIL,DU 1 U2
- 1006-000133 IC-DRIVER/RECEIVER:232,SOP,16P,150MIL,DU 1 U3
- 1106-000131 IC-SRAM:681000,128Kx8BIT,SOP,32P,525MI 1 U16
- 1106-000131 IC-SRAM:681000,128Kx8BIT,SOP,32P,525MI 1 U20
- 1202-000164 IC-VOLTAGE COMP.:393,SOP,8P,150MIL,DUAL, 1 U17
- 1203-000404 IC-DC/DC CONVERTER:34063,SOP,8P,150MIL,P 1 U4
- 1205-001771 IC-CLOCK GENERATOR:FS781BZB,SOP,8PIN 1 U7
- 2007-000026 R-CHIP:200OHM,5%,1/10W,DA,TP,2012 10
R48,R103,R110,R111,R112
R113,R114,R115,R120,R121
- 2007-000028 R-CHIP:39OHM,5%,1/10W,DA,TP,2012 2 R67,R74
- 2007-000030 R-CHIP:560OHM,5%,1/10W,DA,TP,2012 1 R16
- 2007-000290 R-CHIP:100OHM,5%,1/10W,DA,TP,2012 18
R38,R43,R44,R45,R47,R50
R52,R53,R57,R59,R60,R64
R71,R73,R90,R91,R92,R96
- 2007-000300 R-CHIP:10KOHM,5%,1/10W,DA,TP,2012 33
R1,R3,R5,R6,R9,R11,R13
R25,R27,R29,R30,R33,R36
R40,R46,R56,R58,R63,R65
R66,R69,R70,R75,R77,R79
R81,R84,R89,R94,R95,R105
R125,R130
- 2007-000355 R-CHIP:12KOHM,5%,1/10W,DA,TP,2012 5 R97,R61,R76,R85,R87
- 2007-000406 R-CHIP:15KOHM,1%,1/10W,DA,TP,2012 1 R68
- 2007-000457 R-CHIP:18KOHM,5%,1/10W,DA,TP,2012 8
R116,R119,R122,R124,R126
R128,R131,R132
- 2007-000468 R-CHIP:1KOHM,5%,1/10W,DA,TP,2012 7
R7,R8,R32,R39,R41,R72
R117
- 2007-000518 R-CHIP:2.7KOHM,5%,1/10W,DA,TP,2012 1 R93
- 2007-000642 R-CHIP:270OHM,5%,1/10W,DA,TP,2012 3 R80,R83,R104
- 2007-000653 R-CHIP:27KOHM,5%,1/10W,DA,TP,2012 2 R14,R19
- 2007-000686 R-CHIP:3.3KOHM,5%,1/10W,DA,TP,2012 3 R15,R49,R88
- 2007-000872 R-CHIP:4.7KOHM,5%,1/10W,DA,TP,2012 23
R2,R4,R12,R17,R18,R23,R28
R31,R34,R37,R42,R51,R54
R55,R62,R86,R99,R100,R101
R102,R108,R127,R129
- 2007-000931 R-CHIP:470OHM,5%,1/10W,DA,TP,2012 6
R24,R78,R106,R109,R118
R123
- 2007-001039 R-CHIP:56KOHM,5%,1/10W,DA,TP,2012 1 R82
- 2007-001071 R-CHIP:6.8KOHM,5%,1/10W,DA,TP,2012 1 R98
- 2007-001071 R-CHIP:6.8KOHM,5%,1/10W,DA,TP,2012 1 R107
- 2011-001093 R-NETWORK:100ohm,5%,1/16W,L,CHIP,8P,TP 1 RA1
- 2011-001093 R-NETWORK:100ohm,5%,1/16W,L,CHIP,8P,TP 1 RA2
