10 PCB Layout and Parts List
SAM4S ER-380M/F SERIES 10-5
10-1 Main PCB Layout
10-1-1-(b) Parts List
No Part-No Description / Specification Q’TY Design Location
Serviceabl
e
Remark
s
- 2203-000192 C-CERAMIC,CHIP:100nF,+80-20%,50V,Y5V,TP, 36
C3,C9,C10,C25,C29,C40,C43
C44,C46,C47,C49,C56,C57
C58,C62,C63,C64,C65,C67
C72,C73,C75,C76,C78,C81
C82,C84,C85,C86,C87,C88
C89,C90,C91,C93,C95
- 2203-000239 C-CERAMIC,CHIP:0.1nF,5%,50V,NP0,TP,2012 14
C39,C41,C42,C45,C53,C55
C59,C60,C66,C68,C69,C70
C71,C80
- 2203-000260 C-CERAMIC,CHIP:10nF,10%,50V,X7R,TP,2012 3 C74,C79,C61
- 2203-000595 C-CERAMIC,CHIP:0.22nF,5%,50V,NP0,TP,2012 1 C54
- 2203-000634 C-CERAMIC,CHIP:0.022nF,5%,50V,NP0,TP,201 1 C51
- 2203-000634 C-CERAMIC,CHIP:0.022nF,5%,50V,NP0,TP,201 1 C52
- 2203-000938 C-CERAMIC,CHIP:0.47nF,5%,50V,NP0,TP,2012 12
C2,C6,C11,C13,C15,C18,C19
C20,C21,C22,C24,C30
- 2203-000990 C-CERAMIC,CHIP:1uF,+80-20%,25V,Y5V,TP,20 15
C8,C12,C14,C16,C17,C23
C26C28,C31,C32,C33,C35
C36,C37,C38
- 3301-000317 CORE-FERRITE BEAD:AB,2x1.25x0.9mm,-,- 16
L1,L2,L3,L4,L7,L8,L9,L10,L11
L12,L13,L14,L15,L16,L17,L18
- JK41-10552A PCB-MAIN:ER-380M,FR-4,2L,T1.6mm 1
To Next Page
