6 Exploded Views and Parts List
6-10 SAM4S ER-420M/F SERIES
6-2. D. ASS’Y KBD(48KEY RAISED)
No. Parts No. Description / Specification Q`ty Design-Location Serviceable Remark
D JK59-30015A UNIT-KEYBOARD:ER-420,ENGLISH,48K,MEM 1 Y
D-1 JK81-10945A KEY-CAP(S): 1X1 34 Y
D-2 - LABEL-KEY TOP SET: ER-420 1 N
D-3 JK81-20013A KEY-TOP ASS'Y(S): 1X1 34 Y
D-4 JK81-10285T SPRING RETURN: 1X1 46 Y
D-5 JK81-10946A KEY-CAP(L): 1X2 1 Y
D-6 JK81-20014A KEY-TOP ASS'Y(L): 1X2 1 Y
D-7 JK81-20001A SPRING-RETURN: 1X2 2 Y
JK81-10933A KEY-TOP,1 1 Y
JK81-10934A KEY-TOP,2 1 Y
JK81-10935A KEY-TOP,3 1 Y
JK81-10936A KEY-TOP,4 1 Y
JK81-10937A KEY-TOP,5 1 Y
JK81-10938A KEY-TOP,6 1 Y
JK81-10939A KEY-TOP,7 1 Y
JK81-10940A KEY-TOP,8 1 Y
JK81-10941A KEY-TOP,9 1 Y
JK81-10942A KEY-TOP,0 1 Y
JK81-10943A KEY-TOP,00 1 Y
D-8
JK81-10944A KEY-TOP,● 1 Y
D-9 JK72-60448A HOUSING 1 Y
D-10 JK81-10949A FPC ASS’Y 1 Y
D-11 JK70-10422A FRAME(T0.8) 1 Y
D-12 6002-000114 SCREW TAPPING: PH,+,2,M3,L8,ZPC(YEL) 2 Y
