6 Exploded Views and Parts List
6-12 SAM4S ER-420M/F SERIES
6-2. E. ASS’Y CASE-LOWER
No. Parts No. Description / Specification Q`ty Design-Location Serviceable Remark
E-1 JK39-00008A PBA SUB-POWER SW 1 Y
E-2 6002-000174 SCREW-TAPPING: PWH,+,2,M3,L10,ZPC(YEL) 3 Y
E-3 JK39-40642A HARNESS-IF;22PIN 1 Y
E-4 JK39-40603A HARNESS DRA/COM;4PIN,180mm 1 Y
E-5 6003-001149 SCREW-TAPTITE;PWH,+,M4,L10 1 Y
E-6 JK72-40205A PMO-CASE FISICAL BOARD: HIPS(V0) 1 Y FISCAL
JK92-00131A PBA SUB-FISICAL B/D: 512K BYTE 1 Y
FISCAL
JK92-00983A PBA MAIN-1M,FISICAL: 1M BYTE 1 Y FISCAL
E-7
JK92-00132C PBA SUB FISCAL B/D: 2M BYTE 1 Y FISCAL
JK92-01264B PBA MAIN BOARD:ER-420MF 1 Y
JK92-01264C PBA MAIN BOARD:ER-420M 1 Y
JK92-01264D PBA MAIN BOARD:ER-420 1 Y
E-8
JK92-01264E PBA MAIN BOARD:ER-420F 1 Y
E-9 6006-000199 SCREW-ASS’Y TAPT:WT,BH,+,M4,L8,ZPC(YEL) 2 Y
JK26-30511A TRANS-POWER:USA: 120V 60Hz 1 Y
E-10
JK26-00014A TRANS-POWER:EUROPE: 230V 50Hz 1 Y
E-11 6002-000175 SCREW-TAPPING: PWH,+,2,M3,L8 ,ZPC(YEL) 2 Y
E-12 JK92-01227B PBA SUB-POWER SW 1 Y
E-13 JK60-00001A SCREW-ASSYTAPTITE,M3,L8 3 Y
E-14 6006-000187 SCREW-ASS’Y TAPT:WT,BH,+,M4,L6,ZPC(YEL) 1 Y
E-15 6002-000174 SCREW-TAPPING:PWH,+,2,M3,L10,ZPC(YEL) 2 Y
JK92-01280A PBA SUB-I/F:ER-420/M,232*2 1 Y 2 SERIAL
E-16
JK92-01282A PBA SUB-I/F:ER-420/M,232*I,,RJ45*2 1 Y 3 SERIAL
E-17 6002-000175 SCREW-TAPPING: PWH,+,2,M3,L8 ,ZPC(YEL) 3 Y
JK72-00013C PMO-CASE LOWER 1 Y 2 SERIAL
E-18
JK72-00013D PMO-CASE LOWER 1 Y 3 SERIAL
E-19 6002-000171 SCREW-TAPPING: PH,+,2S,M4,L10,ZPC(YEL) 1 Y
E-20 JK70-10002A IPR-BRKT CASING 1 Y
E-21 JK70-20018B IPR-BRKT TRANS 1 Y
JK39-10002A CBF-POWER CORD: AUSTRALIA 1 Y
JK39-10003A CBF-POWER CORD: USA 1 Y
JK39-10008A CBF-POWER CORD: UK 1 Y
E-22
JK39-10501A CBF-POWER CORD: EUROPE 1 Y
E-23 6001-000666 SCREW-MACHINE:PWH,+,M3,L6,ZPC(YEL) 2 Y
E-24 JK72-20111A PMO-COVER SUPPLY:ER-420 1 Y
E-25 JK68-40015A LABEL(P)-SUPPLY 1 Y
E-26 6002-000174 SCREW-TAPPING:PWH,+,2,M3,L10,ZPC(YEL) 4 Y
