7 PCB Layout and Parts List
7-4 SAM4S ER-420M/F SERIES
No Part-No Description / Specification Q’TY Design Location Serviceable Remarks
- 2007-000300 R-CHIP:10KOHM,5%,1/10W,DA,TP,2012 1
R1,R4,R25,R30,R43,R44,R45
R47,R50,R59,R61,R64,R68
R70,R81,R82,R84,R85,R87
R97,R107,R108,R115,R119
R133
Y
- 2007-000352 R-CHIP:12KOHM,1%,1/10W,DA,TP,2012 1 R28 Y
- 2007-000395 R-CHIP:150KOHM,5%,1/10W,DA,TP,2012 1 R56,R79,R88,R93 Y
- 2007-000406 R-CHIP:15KOHM,1%,1/10W,DA,TP,2012 1 R80 Y
- 2007-000457 R-CHIP:18KOHM,5%,1/10W,DA,TP,2012 1
R8,R10,R35,R51,R58
R121,R128
Y
- 2007-000468 R-CHIP:1KOHM,5%,1/10W,DA,TP,2012 1
R12,R31,R41,R48,R49
R52,R71,R72,R127
Y
- 2007-000642 R-CHIP:270OHM,5%,1/10W,DA,TP,2012 1 R95,R98,R100 Y
- 2007-000653 R-CHIP:27KOHM,5%,1/10W,DA,TP,2012 1 R15 Y
- 2007-000653 R-CHIP:27KOHM,5%,1/10W,DA,TP,2012 1 R34 Y
- 2007-000671 R-CHIP:2KOHM,5%,1/10W,DA,TP,2012 1 R11,R117 Y
- 2007-000686 R-CHIP:3.3KOHM,5%,1/10W,DA,TP,2012 1 R21,R46,R60 Y
- 2007-000728 R-CHIP:300OHM,5%,1/10W,DA,TP,2012 1 Y
- 2007-000872 R-CHIP:4.7KOHM,5%,1/10W,DA,TP,2012 1
R5,R23,R26,R32,R33
R36,R63,R69,R94
R101,R103,R105,R116
R120,R129,R131,R132
R134,R135, R110,R111
R112,R122,R123,R124
R125,R140
Y
- 2007-000931 R-CHIP:470OHM,5%,1/10W,DA,TP,2012 1
R14,R37,R114,R118
R126,R130
Y
- 2007-001039 R-CHIP:56KOHM,5%,1/10W,DA,TP,2012 1 R53,R54,R74,R75 Y
- 2007-001071 R-CHIP:6.8KOHM,5%,1/10W,DA,TP,2012 1 R55,R62,R109 Y
- 2007-001662 R-CHIP:36KOHM,1%,1/10W,DA,TP,2012 1 R13,R29, Y
- 2011-001093 R-NETWORK:100ohm,5%,1/16W,L,CHIP,8P,TP 1 RA1,RA2 Y
ER420M
ONLY
- 2203-000192 C-CERAMIC,CHIP:100nF,+80-20%,50V,Y5V,TP, 1
C2,C7,C10,C24,C31
C32,C40,C41,C42,C43
C44,C45,C50,C51,C53
C59,C61,C62,C63,C72
C74,C79,C82,C83,C85
C86,C87,C88,C89,C90
C91,C93,C94,C95,C96
C97,C98,C100,C101
C102,C103
Y
- 2203-000239 C-CERAMIC,CHIP:0.1nF,5%,50V,NP0,TP,2012 1
C36,C55,C58,C64,C65
C66,C71,C76,C77,C78
C80,C81
Y
- 2203-000260 C-CERAMIC,CHIP:10nF,10%,50V,X7R,TP,2012 1 C73,C75 Y
- 2203-000595 C-CERAMIC,CHIP:0.22nF,5%,50V,NP0,TP,2012 1 C57 Y
- 2203-000634 C-CERAMIC,CHIP:0.022nF,5%,50V,NP0,TP,201 1 C52,C56 Y
- 2203-000938 C-CERAMIC,CHIP:0.47nF,5%,50V,NP0,TP,2012 1
C3,C4,C6,C9,C13,C15
C18,C19,C20,C23,C25, C28
Y
- 2203-000990 C-CERAMIC,CHIP:1uF,+80-20%,25V,Y5V,TP,20 1
C8,C11,C12,C16,C17
C22,C26,C27,C29,C30
C33,C34,C35,C37,C38
C104
Y
- 2203-000991 C-CERAMIC,CHIP:0.82nF,5%,50V,NP0,TP,2012 1
C46,C47,C48,C49,C67
C68,C69,C70
Y
- 3301-000317 CORE-FERRITE BEAD:AB,2x1.25x0.9mm,-,- 1 L5,L6,L7,L8,L9 Y
- JK41-10566A PCB-MAIN:ER-420,FR-4,2L,T1.6mm 1 Y
