SECTION III USE
The ends of the lifting rods feature slots that allow wide implements to
adapt to uneven ground.
The lengths of the top link and the lifting rods are adjusted by way of
threaded sleeves fitted with handles for easy operation.
Adjustment of the telescopic stabilisers
The telescopic stabilisers serve to prevent or limit side movement
(transverse oscillation) of the implement.
The stabilisers must be adjusted without free play, when transporting
implements and when working with grader blades, scraper blades, rollers,
mowers, seed drills augers and similar implements.
The stabilisers must be adjusted with a little free play, when working with
with ploughs, harrows, cultivators and similiar implements, or when
working in draft control mode
Adjustment of the top link
This adjustment serves to position the implement at the correct angle to
the ground.
Shortening the top link increases the angle; lengthening the top link
reduces the angle.
Normally, when the lower lift arms are positioned horizontally, the rear end
of the top link should be angled upwards.
The distance between the lower lift arms and the top link must never be
less than 460 mm (18 in) .
70
WARNING: WHEN OPERATING THE LIFT CONTROLS, STAND WELL
CLEAR OF THE OPERATING RADIUS OF THE LIFT ARMS AND ANY
ATTACHED IMPLEMENTS.
THIS IS TO AVOID THE RISK OF INJURY IN THE CASE OF INCOR
-
RECT MANOEUVRES.
WARNING: DO NOT STAND, OR ALLOW ANYONE ELSE TO STAND,
BETWEEN THE TRACTOR AND IMPLEMENT UNLESS THE ENGINE
IS TURNED OFF AND THE PARKING BRAKE IS ENGAGED, THE
LOWEST GEAR IS ENGAGED, THE KEY IS REMOVED, AND ALL AT-
TACHMENTS OR IMPLEMENTS ARE LOWERED TO THE GROUND.
