SECTION VIII TECHNICAL SPECIFICATIONS
Front driving axle
Ratios
front axle reduction gear gearbox - front-wheel drive 32/46 = 1/1.4375
bevel drive 8/31 = 1/3.8750
final drive (19/20) x (12/41) = 1/3.5965
total reduction 1/20,0336
mechanical ratio
(No. of front wheel revs. per rear wheel rev) 1.4725
axle angle of oscillation 10°
inner wheel steering angle
standard axle 57°
narrow axle 45°
Toe-in
-
Hydrostatic steering system
manufacturer SAME DEUTZ-FAHR GROUP
hydraulic lift type with open centre control valve
safety valve setting bar 180
psi 2610
Relief valve setting bar 200
psi 2900
minimum permissible piston diameter mm 74.051
in 2,93
maximum permissible cylinder diameter mm 75.030
in 2,96
lifting capacity with load concentrated
on link arm ball ends at height for rear
wheel centres kg 1200
lb 2644
Front hydraulic lift
Maximum lifting capacity 400 kg (881.84 lb).
