SECTION VI ELECTRICAL SYSTEM
Cab electrical system wiring
1 - Warning beacon switches
2 - Warning beacon
3 - Interior roof light
4 - 12 V power socket for radio
5 - Air conditioning system relay
6 - Condenser fan
7 - Heating and air conditioning
group
8 - Pressure switch
9 - Compressor (R 132a)
10 - Heating unit
11 - Windscreen wiper switch
12 - Front windscreen wiper motor
13 - Front screenwash pump
14 - Screenwash button
15 - Windscreen wiper switch
16 - Rear windscreen wiper motor
17 - Rear screenwash pump
18 - Front work lights switch
19 - Front work lights
20 - Rear work lights switch
21 - Rear work lights
