SECTION V MAINTENANCE
Maintenance of the front and rear brakes
Every 150 hours: check the brake pedals’ free travel.
Checking the braking action
The user should operate the brakes to test the braking action. If the brakes
do not function correctly, contact your authorized service centre.
Controls under platform
(right-hand side)
1 - Differential lock
control
2 - Brakes STOP
indicator (right)
3 - Brakes free travel
adjustment screw
4 - Brakes end of travel
stop screw
Front differential lock (if installed)
Periodically: check front differential lock engagement.
Any necessary inspections should be carried out by one of our Service
Centres and as indicated in the tractor’s “Workshop manual”
Controls under platform
(left-hand side)
1 - Front traction
engagement lever
2 - Brakes STOP
indicator (left side)
3 - Front differential lock
electronic control unit
4 - Parking brake control
fork
5 - Left brake control rod
144
