SAME SOLARIS 35 User Manual

SECTION VI ELECTRICAL SYSTEM
Headlight alignment
The tractor must be in normal road-going conditions and parked on a level
surface at a distance of 10 m (32.8 ft) from a wall (tyres must be inflated to
the correct pressures and the front wheels must be positioned for travel in
a straight line).
Switch on the dipped beam headlights.
1 - points on the wall corresponding to the centres of the headlights
A - distance apart of headlights
H - height of headlights
h - distance of the centre of the beam from the horizontal axis
X - distance between headlights and wall
177
h=10cm
H
X =10 m
H
A

SAME SOLARIS 35 Specifications

General

Engine Power	35 hp
PTO Power	30 hp
Drive	4WD
Hydraulic System	Open center
Hydraulic Remotes	2
Lift Capacity	1200 kg
Engine Type	Diesel
Transmission	12 forward and 12 reverse gears
