SECTION IV WHEELS
Width of the front axle (without
wheels)
35 HP
Narrow 916 mm (36.09 in)
Wide 1050 mm (41.37 in)
45 HP
Narrow 916 mm (36.09 in)
Wide 1050 mm (41.37 in)
55 HP
Narrow 916 mm (36.09 in)
Wide 1200 mm (47.28 in)
Mechanical ratio (front wheel revolutions / rear wheel revolution)
35HP-45HP-55HP 1,4725
Width of rear axle (without wheels)
35 HP
Narrow 762 mm (30.02 in)
Wide 882 mm (34.75 in)
45 HP
Narrow 762 mm (30.02 in)
Wide 966 mm (38.06 in)
55 HP
Narrow 762 mm (30.02 in)
Wide 966 mm (38.06 in)
Row crop tires
When changing the tractor over to row crop (bar tread) tires, observe load
rating and speed limits!
Given the tremendous variety of tyres available, always ask your nearest
dealer for information on alternative tyres and data on homologation,
capacity, pressure, track, etc..
93
