SECTION III USE
6 - Lamp indicating engagement of PTO speed - YELLOW
ON - Indicates rotation of PTO speed shaft .
7 - Parking brake pilot lamp - RED
ON - Parking brake is applied.
8 - Hydraulic services circuit pressure pilot lamp - RED
ON - Signals a pressure drop inside the hydraulic services' circuit.
9 - Warning lamp - RED
ON WHEN ENGINE IS RUNNING: switch the engine off immediately and contact
your Service Centre.
10 - Rear PTO clutch indicator - RED
LIT – Shows that the rear PTO clutch is disengaged.
When the PTO clutch is engaged, the splined drive could start to turn.
11 - Main beam warning light - BLUE
ON - Indicates that the main beam headlights are on.
12 - Lighting on - GREEN
ON - Side lights and driving beams are on.
13 - First trailer direction indicator and hazard lights pilot lamp - GREEN
Flashes to indicate either trailer direction and emergency stop.
14 - Tractor direction indicator and hazard lights pilot lamp - GREEN
Flashes to indicate either the direction of tractor and emergency stop.
15 - Parking brake of trailer pilot lamp - RED
ON - Parking brake is applied.
16 - Fuel reserve pilot lamp - YELLOW
ON - Fuel is running out.
17 - Front-wheel drive pilot lamp - ORANGE
ON - Signals the use of front-wheel drive.
18 - Differential lock engagement pilot lamp - ORANGE
ON - Differential locks are engaged, steering is prevented.
14
CAUTION: BEFORE STARTING THE TRACTOR, CHECK ITS CONDI
-
TION FOR OPERATING SAFETLY ON THE PUBLIC HIGHWAY.
