3.2. Operating features
3.3. Safety features
Not applicable
3.4. Operating principle
Not applicable
Weight
Xcite
®
+
385 g / 0.8 Lbs
Xcite
®
+ Light
579 g / 1.3 Lbs
GUN
Xcite
®
+,
Xcite
®
+ Light
120 bar
/ 1740.45 psi
Xcite
®
+,
Xcite
®
+ Light
240 bar
/ 3481 psi
Xcite
®
+
400 bar
/ 5801.5 psi
Maximum air supply pressure 6 bar / 87 psi
Maximum fluid supply pressure 120 bar
/ 1740.45 psi
240 bar
/ 3481 psi
400 bar
/ 5801.5 psi
Fluid flow rate Depending on the tip (see tip chapter)
Maximum operating temperature
50°C / 122°F
Air consumption (at 22°C / 71.6°F temperature)
(with VX 124 K HVLP aircap)
Air pressure = 1 bar / 14.5 psi at the gun handle
Air pressure = 2 bar / 29 psi at the gun handle
4,8 m3/h
7,2 m3/h
Transfer rate (*)
according to EN 13966-1 standard
86 (±2%)
Seat (removable) Stainless steel Tungsten carbide
Materials en contact with the material Stainless steel, PTFE
Xcite
®
+ fluid fitting
M 1/2 JIC
Xcite
®
+ Light fluid fitting
F 1/2 JIC
Air fitting M 1/4 NPS
Safety system Locking lever + tip protection
Filtration In line on product hose Screen n°6 mounted
(not included Xcite
®
+ Light)
Weighted noise level pressure (LAeq)
(under pressure/ with 09/094 tip
/Air pressure at the gun handle = 1.5 bar / 14.5 psi)
80.7 dBa 82.5 dBa 83.8 dBa
(*) test condition
Material pressure = 60 bar / 870 psi Viscosity = 25 s (CA 4) or 50 mPas.s
Air pressure at the gun handle = 1.5 bar / 14.5 psi Temperature = 25°C / 77° F
Tip: 09/094 Relative humidity = 54%
