8.1.1. Wear part numbers
Guns common parts
(*)
Level 1: 1st emergency parts
Level 2: Wear parts
Item Part number Description Qty
Sales
unit
Spare parts
level (*)
1
- Gun body assembly 1 0 -
2
132 720 020
Airmix
®
aircap VX24 KHVLP equipped
1 1 1
2.1
- • Aircap 1 0 -
2.2
- • Ring 1 0 -
2.3
129 720 075 • Seal, aircap (package of 2) 1 1 1
2.4
132 720 003
• Tip protection for Airmix
®
Xcite
®
aircap
(package of 3)
1 1 1
2.5
150 040 330 • Seal, ring (package of 10) 1 1 1
4
129 732 907
Seat-holder assembly Xcite
®
+ (without seat)
1 1 -
4.1
- • Seat-holder 1 0 -
4.2
129 729 913
• Xcite
®
seat holder thread protection O-Ring
(package of 10)
1 1 1
4.3
150 040 329 • O-Ring (package of 10) 1 1 1
4.4
129 729 912
• Aircap seal on Xcite
®
seat holder (package of 5)
1 1 1
4.5
029 600 106 • Screw for seat 1 1 -
4.6
129 740 910 • Diffusor (package of 10) 1 1 1
5
129 725 909
Trigger + safety lever Xcite
®
Light
1 1 1
5.1
- • Screw, HM 3x8, stainless steel 1 0 -
5.2
- • Spindle, trigger 1 0 -
5.3
- • Trigger 1 0 -
5.4
- • Pin 1 0 -
5.5
- • Safety lever 1 0 -
6
129 733 211
Xcite
®
+
cartridge stop (package of 5)
1 1 1
10
129 720 030 Air valve assembly 1 1 1
10.1
050 311 321 • Valve spring 1 1 -
12
- Needle carrier 1 0 -
13
- Needle rod 1 0 -
14
109 420 298 Cartridge seal FKM (package of 10) 1 1 1
15
129 720 020
Xcite
®
assembled air needle
1 1 1
15.1
150 040 328 • O-Ring (package of 10) 1 1 1
15.2
102 202 101 • Ring Ø 5 (package of 10) 1 1 1
15.3
- • Air needle sleeve 1 0 -
19
050 102 624 Air fitting, M 1/4 NPS stainless steel 1 1 -
